Power
Three-core terminal block,
DC: 12 V, 0.94 A, max. 11.24 W,
PoE: IEEE 802.3at Class 4, max. 13.37 W
Dimension
290.8 mm × 162.5 mm × 141 mm (11.45" × 6.4" × 5.55")
Package Dimension
753 mm × 313 mm × 424 mm (29.65" × 12.32" × 16.69")
Weight
Appox. 6.245 kg (13.77 lb.)
With Package Weight
Appox. 7.96 kg (17.55 lb.)
Startup and Operating Conditions
Air cooling (with 20 °C (68 °F) air):
1. Ambient temperature 150°C (302 °F), pressure 0.1 MPa, air volume 20 m³/h, internal body temperature 54°C (129.2 °F)
2. Ambient temperature 125°C (257 °F), pressure 0.1 MPa, air volume 18 m³/h, internal body temperature 49°C (120.2 °F)
3. Ambient temperature 100°C (212 °F), pressure 0.1 MPa, air volume 14 m³/h, internal body temperature 43°C (109.4 °F)
4. Ambient temperature 85°C (185 °F), pressure 0.1 MPa, air volume 10 m³/h, internal body temperature 41°C (105.8 °F)
Humidity 95% or less (non-condensing)
*It is necessary to protect the cable from heat when the ambient temperature of the cable is above 120 °C (248 °F).
Language
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Linkage Method
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture
General Function
Anti-banding, three streams, heartbeat, mirror, flash log, password reset via email, pixel counter
