FQ50

Thermal Monocular

  • 640 x 512 resolution with 12μm sensor
  • High sensitivity thermal module NETD < 20 mK (@25° C, F#=1.0)
  • Super large aperture F0.9
  • Replaceable and rechargeable Li-ion battery
  • Up to 5 hours continuous operation
  • Leading thermal image processing technology: Image Pro
  • 1024 x 768 resolution 0.39-inch OLED display

View Less
View more
Data Sheet
Sales Inquiry

Available models:

HM-TS46-50XG/W-FQ50
FQ50
Data Sheet

Specification

  • Thermal Module
  • Image SensorVOx Uncooled Focal Plane Arrays
  • Resolution640×512
  • Frame Rate50Hz
  • Pixel Interval12μm
  • Response Waveband8μm to 14μm
  • NETDLess than 20 mK (@25°C),F#=1.0
  • Focal Length50mm
  • ApertureF0.9
  • Min. Focusing Distance5.0m
  • Digital Zoom1×，2×，4×，8×
  • Field of View(H × V), Degrees / m @100m8.75°×7°/15.3m×12.2m
  • Optical Magnification2.6
  • Detection Range2600m
  • Image Display
  • Monitor 0.39 inch, OLED, 1024 ×768
  • PalettesBlack Hot, White Hot, Red Hot, Fusion
  • FFC (Flat Field Correction) ModeAuto,Manual,External Correction
  • System
  • StorageBuilt-in memory module (64 GB)
  • Record VideoYes
  • Capture SnapshotYes
  • Standby ModeYes
  • HotspotYes
  • Hot TrackYes
  • Power Supply
  • Power5V，1.95W
  • Battery TypeReplaceable and Rechargeable Li-ion Battery
  • Battery Operating Time5 hours continuous running with CVBS and hotspot function off (@25°C)
  • General
  • Work Temperature/HumidityFrom -30°C to 55°C (-22°F to 131°F); Humidity: 90% or Less
  • Protection LevelIP67
  • Dimension203mm × 78 mm × 67.8 mm (7.99" × 3.07" × 2.67")
  • Weight636g (1.40 lb)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Thermal Module
Image Sensor
VOx Uncooled Focal Plane Arrays
Resolution
640×512
Frame Rate
50Hz
Pixel Interval
12μm
Response Waveband
8μm to 14μm
NETD
Less than 20 mK (@25°C),F#=1.0
Focal Length
50mm
Aperture
F0.9
Min. Focusing Distance
5.0m
Digital Zoom
1×，2×，4×，8×
Field of View(H × V), Degrees / m @100m
8.75°×7°/15.3m×12.2m
Optical Magnification
2.6
Detection Range
2600m
Image Display
Monitor
0.39 inch, OLED, 1024 ×768
Palettes
Black Hot, White Hot, Red Hot, Fusion
FFC (Flat Field Correction) Mode
Auto,Manual,External Correction
System
Storage
Built-in memory module (64 GB)
Record Video
Yes
Capture Snapshot
Yes
Standby Mode
Yes
Hotspot
Yes
Hot Track
Yes
Power Supply
Power
5V，1.95W
Battery Type
Replaceable and Rechargeable Li-ion Battery
Battery Operating Time
5 hours continuous running with CVBS and hotspot function off (@25°C)
General
Work Temperature/Humidity
From -30°C to 55°C (-22°F to 131°F); Humidity: 90% or Less
Protection Level
IP67
Dimension
203mm × 78 mm × 67.8 mm (7.99" × 3.07" × 2.67")
Weight
636g (1.40 lb)
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specification
Thermal Module
  • Image SensorVOx Uncooled Focal Plane Arrays
  • Resolution640×512
  • Frame Rate50Hz
  • Pixel Interval12μm
  • Response Waveband8μm to 14μm
  • NETDLess than 20 mK (@25°C),F#=1.0
  • Focal Length50mm
  • ApertureF0.9
  • Min. Focusing Distance5.0m
  • Digital Zoom1×，2×，4×，8×
  • Field of View(H × V), Degrees / m @100m8.75°×7°/15.3m×12.2m
  • Optical Magnification2.6
  • Detection Range2600m
Image Display
  • Monitor 0.39 inch, OLED, 1024 ×768
  • PalettesBlack Hot, White Hot, Red Hot, Fusion
  • FFC (Flat Field Correction) ModeAuto,Manual,External Correction
System
  • StorageBuilt-in memory module (64 GB)
  • Record VideoYes
  • Capture SnapshotYes
  • Standby ModeYes
  • HotspotYes
  • Hot TrackYes
Power Supply
  • Power5V，1.95W
  • Battery TypeReplaceable and Rechargeable Li-ion Battery
  • Battery Operating Time5 hours continuous running with CVBS and hotspot function off (@25°C)
General
  • Work Temperature/HumidityFrom -30°C to 55°C (-22°F to 131°F); Humidity: 90% or Less
  • Protection LevelIP67
  • Dimension203mm × 78 mm × 67.8 mm (7.99" × 3.07" × 2.67")
  • Weight636g (1.40 lb)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Resources

For better user experience, we highly recommend you to update your device to the latest firmware asap.
Firmware_V5.5.85_240425
Applied to:
HM-TS46-50XG/W-FQ50
