2MP Powered by darkfighter Fixed Bullet 4G Network Camera

High quality imaging with 2 MP resolution
Clear imaging against strong back light due to 120 dB true WDR technology
LTE-TDD/LTE-FDD/WCDMA/GSM 4G wireless network transmission, support Micro SIM card
Camera: Water and dust resistant (IP67)

View Less

Data Sheet

Available models:

DS-2CD3T23G1-I/4G(2.8mm)

DS-2CD3T23G1-I/4G(4mm)

DS-2CD3T23G1-I/4G(8mm)

DS-2CD3T23G1-I/4G

Specification
Resources
Accessories

Data Sheet

Camera
Image Sensor1/2.8" Progressive Scan CMOS
Max. Resolution1920 × 1080
Min. IlluminationColor: 0.004 Lux @ (F1.4, AGC ON),B/W: 0 Lux with IR
Shutter Time1 s to 1/100,000 s
Day & NightIR cut filter

Lens
Lens TypeFixed focal lens, 2.8, 4, and 8 mm optional
Focal Length & FOV2.8 mm, Horizontal FOV: 107°, vertical FOV: 57°, diagonal FOV: 128° 4 mm, Horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102° 8 mm, Horizontal FOV: 41°, vertical FOV: 22°, diagonal FOV: 47°
ApertureF1.4 (2.8 mm and 4 mm models support) F1.6 (8 mm model supports)
Lens MountM12

DORI
DORI2.8 mm: D: 44 m, O: 17.5 m, R: 9 m, I: 4.5 m 4 mm: D: 53 m, O: 21 m, R: 11 m, I: 5 m 8 mm: D: 110 m, O: 44 m, R: 22 m, I: 11 m

Illuminator
Supplement Light TypeIR
Supplement Light RangeUp to 30 m
IR Wavelength850 nm
Smart Supplement LightYes

Video
Main Stream50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Third Stream50Hz: 1fps (1280 × 720, 640 × 480) 60Hz: 1fps (1280 × 720, 640 × 480)
Video Compression Main stream: H.265+/H.265/H.264+/ H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264
Video Bit Rate32 Kbps to 8 Mbps
H.264 TypeBaseline Profile,Main Profile,High Profile
H.265 TypeMain Profile
Bit Rate ControlCBR,VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region of Interest (ROI) 4 fixed regions for each stream
Target CroppingYes

Network
Simultaneous Live ViewUp to 6 channels
APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
User/HostUp to 32 users 3 user levels: administrator, operator, and user
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, TLS 1.2
Network StorageNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClientiVMS-4200,Hik-Connect,Hik-Central
Web BrowserPlug-in required live view: IE8+, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+, Local service: Chrome 41.0+, Firefox 30.0+

Mobile Communication
FrequencyLTE-TDD: Band38/40/41； LTE-FDD: Band1/3/5/7/8/20/28； WCDMA: Band1/5/8 GSM: Band3/5/8
StandardLTE-TDD,LTE-FDD,WCDMA,GSM

Wide Dynamic Range (WDR)120 dB
Day/Night SwitchDay,Night,Auto,Schedule
Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
Image EnhancementBLC,HLC,3D DNR,Defog
Image Parameters SwitchYes
Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
SNR≥ 52 dB
Privacy Mask4 programmable polygon privacy masks

Interface
RS-4851 RS-485 (Half duplex)
On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Reset KeyYes
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port

Event
Basic Event Motion detection,video tampering alarm,exception
Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection,object removal detection, scene change detection, *The smart events are only supported in full power mode.
LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture

General
Power 12 VDC ± 25%, 0.33 A, max. 4 W
Web Client Language33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General FunctionHeartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions-15 °C to 55 °C (-15 °F to 5 °F). Humidity 95% or less (non-condensing)
Material Cover: Metal, main body: Plastic
Dimension219 mm × 114.3 mm × 109.3 mm (8.62" × 4.5" × 4.3")
Package Dimension826 mm × 469 mm × 444 mm (32.5" × 18.5" × 17.5")
WeightApprox. 1,070 g (2.36 lb.)
With Package WeightApprox. 1,900 g (4.18 lb.)

Approval
EMC CE-EMC: EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015
RFCE-RED: EN 301489-1 V2.2.3; EN 301489-52 V1.1.0; EN 62311:2008, ICASA: EN 301 489-1 V2.2.3; EN 301 489-52 V1.1.0;EN 62311:2008
Safety CB: IEC 60950-1:2005 + Am 1:2009 + Am 2:2013;IEC 62368-1:2014, CE-LVD: EN 60950-1:2005 + Am 1:2009 + Am 2:2013;EN 62368-1:2014+A11:2017
EnvironmentCE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
ProtectionIP67: IEC 60529-2013

Camera

Image Sensor

1/2.8" Progressive Scan CMOS

Max. Resolution

1920 × 1080

Min. Illumination

Color: 0.004 Lux @ (F1.4, AGC ON),B/W: 0 Lux with IR

Shutter Time

1 s to 1/100,000 s

Day & Night

IR cut filter

Lens

Lens Type

Fixed focal lens, 2.8, 4, and 8 mm optional

Focal Length & FOV

2.8 mm, Horizontal FOV: 107°, vertical FOV: 57°, diagonal FOV: 128° 4 mm, Horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102° 8 mm, Horizontal FOV: 41°, vertical FOV: 22°, diagonal FOV: 47°

Aperture

F1.4 (2.8 mm and 4 mm models support) F1.6 (8 mm model supports)

Lens Mount

M12

DORI

2.8 mm: D: 44 m, O: 17.5 m, R: 9 m, I: 4.5 m 4 mm: D: 53 m, O: 21 m, R: 11 m, I: 5 m 8 mm: D: 110 m, O: 44 m, R: 22 m, I: 11 m

Illuminator

Supplement Light Type

Supplement Light Range

Up to 30 m

IR Wavelength

850 nm

Smart Supplement Light

Yes

Video

Main Stream

50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub-Stream

50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)

Third Stream

50Hz: 1fps (1280 × 720, 640 × 480) 60Hz: 1fps (1280 × 720, 640 × 480)

Video Compression

Main stream: H.265+/H.265/H.264+/ H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264

Video Bit Rate

32 Kbps to 8 Mbps

H.264 Type

Baseline Profile,Main Profile,High Profile

H.265 Type

Main Profile

Bit Rate Control

CBR,VBR

Scalable Video Coding (SVC)

H.264 and H.265 encoding

Region of Interest (ROI)

4 fixed regions for each stream

Target Cropping

Yes

Network

Simultaneous Live View

Up to 6 channels

API

Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS

User/Host

Up to 32 users 3 user levels: administrator, operator, and user

Security

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, TLS 1.2

Network Storage

NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

Client

iVMS-4200,Hik-Connect,Hik-Central

Web Browser

Plug-in required live view: IE8+, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+, Local service: Chrome 41.0+, Firefox 30.0+

Mobile Communication

Frequency

LTE-TDD: Band38/40/41； LTE-FDD: Band1/3/5/7/8/20/28； WCDMA: Band1/5/8 GSM: Band3/5/8

Standard

LTE-TDD,LTE-FDD,WCDMA,GSM


Wide Dynamic Range (WDR)

120 dB

Day/Night Switch

Day,Night,Auto,Schedule

Picture Overlay

LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.

Image Enhancement

BLC,HLC,3D DNR,Defog

Image Parameters Switch

Yes

Image Settings

Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser

SNR

≥ 52 dB

Privacy Mask

4 programmable polygon privacy masks

Interface

RS-485

1 RS-485 (Half duplex)

On-Board Storage

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB

Reset Key

Yes

Ethernet Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port

Event

Basic Event

Motion detection,video tampering alarm,exception

Smart Event

Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection,object removal detection, scene change detection, *The smart events are only supported in full power mode.

Linkage

Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture

General

Power

12 VDC ± 25%, 0.33 A, max. 4 W

Web Client Language

33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

General Function

Heartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding

Storage Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup and Operating Conditions

-15 °C to 55 °C (-15 °F to 5 °F). Humidity 95% or less (non-condensing)

Material

Cover: Metal, main body: Plastic

Dimension

219 mm × 114.3 mm × 109.3 mm (8.62" × 4.5" × 4.3")

Package Dimension

826 mm × 469 mm × 444 mm (32.5" × 18.5" × 17.5")

Weight

Approx. 1,070 g (2.36 lb.)

With Package Weight

Approx. 1,900 g (4.18 lb.)

Approval

EMC

CE-EMC: EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015

CE-RED: EN 301489-1 V2.2.3; EN 301489-52 V1.1.0; EN 62311:2008, ICASA: EN 301 489-1 V2.2.3; EN 301 489-52 V1.1.0;EN 62311:2008

Safety

CB: IEC 60950-1:2005 + Am 1:2009 + Am 2:2013;IEC 62368-1:2014, CE-LVD: EN 60950-1:2005 + Am 1:2009 + Am 2:2013;EN 62368-1:2014+A11:2017

Environment

CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006

Protection

IP67: IEC 60529-2013
