PTZ-N2C200C-DE

2-inch 2 MP Fixed Powered by DarkFighter IR Network Speed Dome

  • High quality imaging with 2 MP resolution
  • Clear imaging against strong back light due to DWDR technology
  • 3D DNR technology delivers clean and sharp images
  • HiLookVision cloud service and APP for remote management and views of devices
  • Built-in microphone and speakerfor real-time audio security
  • Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
  • Water and dust resistant IP66

View Less
View more
Data Sheet
Sales Inquiry

Available models:

PTZ-N2C200C-DE(F0)
PTZ-N2C200C-DE(F1)
PTZ-N2C200C-DE
Data Sheet

Specification

  • Camera
  • Image Sensor1/2.7" Progressive Scan CMOS
  • Max. Resolution1920 × 1080
  • Min. IlluminationColor: 0.001 Lux @(F1.0, AGC ON), 0 Lux with Light
  • Lens
  • Focal Length2.8 mm/4 mm
  • FOV2.8 mm, horizontal FOV 106.1°, vertical FOV 55.8°, diagonal FOV 126.5° 4 mm, horizontal FOV 83.6°, vertical FOV 44.6°, diagonal FOV 99.1°
  • ApertureF1.0
  • Illuminator
  • Supplement Light TypeWhite Light
  • Supplement Light RangeWhite Light Distance: up to 30 m
  • Smart Supplement LightYes
  • PTZ
  • Movement Range (Pan)0° to 340°
  • Movement Range (Tilt)-5° to 105°
  • Pan SpeedPan speed: configurable from 4° to 21°/s
  • Tilt SpeedTilt speed: configurable from 4° to 19°/s
  • Video
  • Video CompressionH.265, H.264, MJPEG
  • H.264 TypeBaseline Profile, Main Profile, High Profile
  • H.265 TypeMain Profile
  • Main Stream50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
  • Sub-Stream50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
  • Video Bit Rate32 Kbps to 8 Mbps
  • Audio
  • Audio CompressionG.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/AAC-LC/PCM
  • Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate8 kHz/16 kHz
  • Environment Noise FilteringYes
  • Network
  • ProtocolsIPv4/IPv6, HTTP, HTTPS, Qos, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, Bonjour
  • APIOpen Network Video Interface, ISAPI, SDK
  • Image
  • Image SettingsSaturation, brightness, contrast, sharpness
  • Wide Dynamic Range (WDR)Digital WDR
  • Image EnhancementBLC, HLC, 3D DNR
  • Interface
  • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-board StorageBuilt-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
  • Built-in MicrophoneYes
  • Built-in SpeakerYes
  • ResetYes
  • Event
  • Basic EventMotion detection, video tampering alarm, exception
  • Alarm LinkageUpload to FTP, notify surveillance center, send email, upload to memory card
  • General
  • Operating ConditionWith supplement light on: -30 ℃ to 40 ℃. Humidity 95% or less (non-condensing) With supplement light off: -30 ℃ to 50 ℃. Humidity 95% or less (non-condensing)
  • General FunctionMirror, password protection, watermark
  • Power12 VDC ± 25%, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.3 A, max. 10 W
  • DimensionsCamera dimension: 162 mm × 120 mm × 234.2 mm (6.4" × 4.7" × 9.2") Package dimension: 205 mm × 167 mm × 289 mm (8.1" × 6.6" × 11.4")
  • WeightCamera weight: 780 g (1.7 lb.) With package weight: 1280 g (2.8 lb.)
  • Approval
  • EMCFCC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014; IC: ICES-003: Issue 7
  • ProtectionIP66 (IEC 60529-2013)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Camera
Image Sensor
1/2.7" Progressive Scan CMOS
Max. Resolution
1920 × 1080
Min. Illumination
Color: 0.001 Lux @(F1.0, AGC ON), 0 Lux with Light
Lens
Focal Length
2.8 mm/4 mm
FOV
2.8 mm, horizontal FOV 106.1°, vertical FOV 55.8°, diagonal FOV 126.5° 4 mm, horizontal FOV 83.6°, vertical FOV 44.6°, diagonal FOV 99.1°
Aperture
F1.0
Illuminator
Supplement Light Type
White Light
Supplement Light Range
White Light Distance: up to 30 m
Smart Supplement Light
Yes
PTZ
Movement Range (Pan)
0° to 340°
Movement Range (Tilt)
-5° to 105°
Pan Speed
Pan speed: configurable from 4° to 21°/s
Tilt Speed
Tilt speed: configurable from 4° to 19°/s
Video
Video Compression
H.265, H.264, MJPEG
H.264 Type
Baseline Profile, Main Profile, High Profile
H.265 Type
Main Profile
Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
Video Bit Rate
32 Kbps to 8 Mbps
Audio
Audio Compression
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/AAC-LC/PCM
Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate
8 kHz/16 kHz
Environment Noise Filtering
Yes
Network
Protocols
IPv4/IPv6, HTTP, HTTPS, Qos, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, Bonjour
API
Open Network Video Interface, ISAPI, SDK
Image Settings
Saturation, brightness, contrast, sharpness
Wide Dynamic Range (WDR)
Digital WDR
Image Enhancement
BLC, HLC, 3D DNR
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-board Storage
Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
Built-in Microphone
Yes
Built-in Speaker
Yes
Reset
Yes
Event
Basic Event
Motion detection, video tampering alarm, exception
Alarm Linkage
Upload to FTP, notify surveillance center, send email, upload to memory card
General
Operating Condition
With supplement light on: -30 ℃ to 40 ℃. Humidity 95% or less (non-condensing) With supplement light off: -30 ℃ to 50 ℃. Humidity 95% or less (non-condensing)
General Function
Mirror, password protection, watermark
Power
12 VDC ± 25%, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.3 A, max. 10 W
Dimensions
Camera dimension: 162 mm × 120 mm × 234.2 mm (6.4" × 4.7" × 9.2") Package dimension: 205 mm × 167 mm × 289 mm (8.1" × 6.6" × 11.4")
Weight
Camera weight: 780 g (1.7 lb.) With package weight: 1280 g (2.8 lb.)
Approval
EMC
FCC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014; IC: ICES-003: Issue 7
Protection
IP66 (IEC 60529-2013)
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specification
Camera
  • Image Sensor1/2.7" Progressive Scan CMOS
  • Max. Resolution1920 × 1080
  • Min. IlluminationColor: 0.001 Lux @(F1.0, AGC ON), 0 Lux with Light
Lens
  • Focal Length2.8 mm/4 mm
  • FOV2.8 mm, horizontal FOV 106.1°, vertical FOV 55.8°, diagonal FOV 126.5° 4 mm, horizontal FOV 83.6°, vertical FOV 44.6°, diagonal FOV 99.1°
  • ApertureF1.0
Illuminator
  • Supplement Light TypeWhite Light
  • Supplement Light RangeWhite Light Distance: up to 30 m
  • Smart Supplement LightYes
PTZ
  • Movement Range (Pan)0° to 340°
  • Movement Range (Tilt)-5° to 105°
  • Pan SpeedPan speed: configurable from 4° to 21°/s
  • Tilt SpeedTilt speed: configurable from 4° to 19°/s
Video
  • Video CompressionH.265, H.264, MJPEG
  • H.264 TypeBaseline Profile, Main Profile, High Profile
  • H.265 TypeMain Profile
  • Main Stream50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
  • Sub-Stream50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
  • Video Bit Rate32 Kbps to 8 Mbps
Audio
  • Audio CompressionG.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/AAC-LC/PCM
  • Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate8 kHz/16 kHz
  • Environment Noise FilteringYes
Network
  • ProtocolsIPv4/IPv6, HTTP, HTTPS, Qos, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, Bonjour
  • APIOpen Network Video Interface, ISAPI, SDK
  • Image SettingsSaturation, brightness, contrast, sharpness
  • Wide Dynamic Range (WDR)Digital WDR
  • Image EnhancementBLC, HLC, 3D DNR
Interface
  • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-board StorageBuilt-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
  • Built-in MicrophoneYes
  • Built-in SpeakerYes
  • ResetYes
Event
  • Basic EventMotion detection, video tampering alarm, exception
  • Alarm LinkageUpload to FTP, notify surveillance center, send email, upload to memory card
General
  • Operating ConditionWith supplement light on: -30 ℃ to 40 ℃. Humidity 95% or less (non-condensing) With supplement light off: -30 ℃ to 50 ℃. Humidity 95% or less (non-condensing)
  • General FunctionMirror, password protection, watermark
  • Power12 VDC ± 25%, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.3 A, max. 10 W
  • DimensionsCamera dimension: 162 mm × 120 mm × 234.2 mm (6.4" × 4.7" × 9.2") Package dimension: 205 mm × 167 mm × 289 mm (8.1" × 6.6" × 11.4")
  • WeightCamera weight: 780 g (1.7 lb.) With package weight: 1280 g (2.8 lb.)
Approval
  • EMCFCC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014; IC: ICES-003: Issue 7
  • ProtectionIP66 (IEC 60529-2013)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
